Light Plastic Pipe Clamp / Tube Clamps / Hydraulic Hose Clamps / PP Clamp Body / DIN 3015 / O.D. 6mm -102mm / Light duty pipe clamps / Standard Hydraulic Pipe Clamps

Material	Carbon steel , Stainless Steel 304 , Stainless steel 316 , As per client Request.
Material	Jaws – Polypropylene, Polyamide, Aluminum
Color	Green
Structure	Hydraulic
Usage/Application	Pipe Fitting
Clamp Type	HYDRAULIC
Surface Type	Galvanized
Condition	New
Din	3015
Type	Standard (Light Duty)
Size	1 /4’’ to 2 ½’’ – 6 mm to 76.1 mm
Working Temperature	PP -30 centi degree up to +90 centi degree in dark green colour PA -40 centi degree up to +120 centi degree in dark colour Alu. for high temperature application, upto 500 ℃.
Pressure	1500 PSI for Light Duty and more than 1500 PSI for Heavy Duty

Light series hydraulic hose clamps, pipe clamps, tube clamps are designed to German standard DIN 3015-1, this series of productsare designed for fastening pipes, tubes and hoses under normal mechanical pressure and vibration.

Tube and hydraulic hose clamps and our product prices are quite competitive.DIN 3015 series light duty pipe, tube, and hydraulic hose clamps are with the same specifications, dimensions and features as the standard series Stauff pipe clamps.

The most popular materials of our clamp Body are available in Polypropylene(PP), Polyamide(PA), Aluminum(Al), beside the above, we also produce clamp body in materials of steel, stainless steel and POM on requests.

Pipe, tube and hydraulic hose clamps are featured by strong strength, accurate dimensions, good corrosion resistance and durable in use, and good surface quality. So the products are widely exported to many countries like UK, Australia,Indonesia Germany, Vietnam, France, USA, Mexico, Brazil, Croatia, South Africa, Canada, Spain,Korea,Russia, and so on.
